Conventional certification that data cable manufacturers must know!
Conventional certification that data cable manufacturers must know!
1. Global scope
Cable and cable certification: CB certification (CB member countries mutually recognize CB test reports and certificates, and use this as the basis for obtaining national certification)
1. Applicable products
IEC 60227 series rubber, PVC and other cables
IEC60245 series wire and cable such as elevator / welder
IEC60502 series power cable
2. Authentication mode
Type test + initial factory inspection and product consistency confirmation inspection + post-certification supervision.
3. The basic link of certification
Application for certification
Type test
Evaluation and certification of certification results
2, the Americas
Certification for cables and cables: UL certification
1. Applicable products
Equipment wiring materials
Building wire
Flexible power cable
High-speed audio / video interface cable
Local Area Network (LAN) cable
optical fiber
Communication Cable
2. Authentication mode
Type test + initial factory inspection and product consistency confirmation inspection + post-certification supervision.
3. The basic link of certification
Application for certification
Type test
Initial factory inspection and product consistency confirmation inspection
Evaluation and approval of certification results
Supervision and audit after certification
3. EU, Middle East, Africa
Certification for cables and cables: VDE certification
1. Which cable products are applicable
? Copper core PVC insulated and sheathed flexible cable:
HO3VVH2-F, HO3VV-F, H03VVH8-F, H03VVH2H8-F, H03V2V2-F, H03V2V2H2-F
HO5VVH2-F, H05VV-F, H05V2-R, H05V2V2-F, H05V2V2H2-F
? Low smoke halogen free wire
H03Z1Z1-F, H03Z1Z1H2-F H05Z1Z1-F, H05Z1Z1H2-F, H07ZZ-F
? Rubber wire
HO7RR-F, HO7RN-F
? Special PVC T11 core insulation
H07V-K, H07V2-K H05V2-K, H05V-K
? Electrical equipment cable
H07V-U, H07V2-U H05V2-U H05V-U
2. Authentication mode
Type test
3. The basic link of certification
Application for certification
Type test
Initial factory inspection and product consistency confirmation inspection
Evaluation and approval of certification results
Supervision and audit after certification
4. China
Certification for cables and cables: CCC certification
1. Applicable product range
a) Mine rubber flexible cable;
b) Wire and cable for railway locomotives with AC rated voltage of 3kV and below;
c) Rubber insulated wire and cable with rated voltage 450 / 750V and below;
d) PVC insulated wire and cable with rated voltage 450 / 750V and below.
2. Inapplicable product range
Not applicable to wire assembly products, nor to bare wires, power cables, overhead insulated cables, communication cables, optical cables, winding wire products.
3. Authentication mode
Type test + initial factory inspection and product consistency confirmation inspection + post-certification supervision.
4. The basic link of certification
Application for certification
Type test
Initial factory inspection and product consistency confirmation inspection
Evaluation and approval of certification results
Supervision and audit after certification
As a data line manufacturer, do you know these certifications?
